sff optical transceiver module

Description

Products Description

Features

Single 3. 3V Power supply and CML Logic Interface

Small Form Factor 2X5 pin Package,Duplex LC Transceiver

Operating data rate up to 155Mbps

850nm VCSEL Laser Transmitter：

Distance up to 2Km for Multi-Mode Optical Fiber

1310nm FP Laser Transmitter：

Distance up to 2Km for Multi-Mode Optical Fiber

1310nm DFB Laser Transmitter：

Distance up to 40km for Single-Mode Optical Fiber

1550nm DFB Laser Transmitter：

Distance up to 200km for Single-Mode Optical Fiber

Operating case temperature:

Standard(C): 0℃~+70℃

Industrial(I): -40℃~+85℃

Applications

Ethernet Links

Fiber Channel Links

Other Optical Link

Ordering information

Table-1 Ordering information

Part Number	Data Rate	Wavelength	Distance	Fiber^{Note 3}	DDM	Interface	Temp.
GACF-8503-02x^{Note 1}xx^{Note 2}	155M	850nm	2km	MMF	N	Duplex LC	C/I
GACF-1303-02x^{Note 1}xx^{Note 2}	155M	1310nm	2km	MMF	N	Duplex LC	C/I
GACF-1303-10x^{Note 1}xx^{Note 2}	155M	1310nm	10km	SMF	N	Duplex LC	C/I
GACF-1303-20x^{Note 1}xx^{Note 2}	155M	1310nm	20km	SMF	N	Duplex LC	C/I
GACF-1303-40x^{Note 1}xx^{Note 2}	155M	1310nm	40km	SMF	N	Duplex LC	C/I
GACF-1503-40x^{Note 1}xx^{Note 2}	155M	1550nm	40km	SMF	N	Duplex LC	C/I
GACF-1503-80x^{Note 1}xx^{Note 2}	155M	1550nm	80km	SMF	N	Duplex LC	C/I
GACF-1503-K2x^{Note 1}xx^{Note 2}	155M	1550nm	120km	SMF	N	Duplex LC	C/I
GACF-1503-K6x^{Note 1}xx^{Note 2}	155M	1550nm	160km	SMF	N	Duplex LC	C/I
GACF-1503-2Kx^{Note 1}xx^{Note 2}	155M	1550nm	200km	SMF	N	Duplex LC	C/I

Note 1: “x”=space, Standard: 0℃~+70℃; “x”=I, Industrial: -40℃~+85℃.

Note 2: “xx” is transmitter optical output close or open and Optical receiver Input indicated.

Transmitter optional as below:

B= Tx-BEN ( 0- close the laser 1- open the laser);D=Tx-DIS (0-open the laser 1-close the laser)

Receiver optional as below:

S=RX-SD （0-signal loss 1-signal valid);L=Rx-LOS (0- signal valid 1-signal loss)

So complete Part No. is GACF-1303-02DS

Note 3: “MMF” stands for 50/125µm MMF；“SMF” stands for 9/125µm SMF

Absolute Maximum Ratings

Table-2 Absolute Maximum Ratings

Parameter	Symbol	Min	Typ	Max	Unit	Notes
Supply Voltage	Vcc	-0.5	-	+3.6	V
Storage Temperature	TS	-45	-	90	°C
Operating Relative Humidity	RH	+5	-	+95	%
Lead Solder Temperature	-	-	-	260	℃
Lead Solder Duration	-	-	-	10	Sec

Operating Environment

Table 3-Operating Environment

Parameter	Condition	Unit	Min.	Typ.	Max.
Power Supply Voltage	+3.3v Supply Voltage	V	3.13	3.3	3.47
Power Dissipation		W	-	-	1.0
Operating Case Temperature	Standard	℃	0	-	70
Operating Case Temperature	Industrial	℃	-40	-	85

Performance specifications-Electrical

Table 4-Performance specifications-Electrical

Parameter	Symbol	Min	Typ.	Max	Unit	Notes
Transmitter
Differential Data Input Swing	Vin	400	-	1200	mVpp
Input Impedance (Differential)	Zin	85	100	115	ohm
Tx_DISABLE Input Voltage -High	VD	2	-	3.45	V
Tx_DISABLE Input Voltage -Low	VEN	0	-	0.8	V
Receiver
Differential Date Output Swing	Vout	350	-	950	mVpp
Output Impedance (Differential)	Zout	85	100	115	ohm
Rx_SD Output Voltage -High	VOH	2	-	Vcc+0.3	V
Rx_SD Output Voltage -Low	VOL	0	-	0.8	V

Optical Characteristics

Table 5.1-GACF-8503-02xx (SFF 2x5 155M 850nm 2km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	km	-	-	2	1
Center Wavelength Range	λc	nm	830	850	870
Spectral Width(RMS)	Δλ	nm	-	-	0.85
Launch Optical Power	P₀	dBm	-9	-	-3	1
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	830	850	870
Receiver Sensitivity	Sens	dBm	-	-	-19	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-35	-	-
SD Assert	SDA	dBm	-	-	-20
SD Hysteresis		dB	0.5	-	-	6

Table 5.2-GACF-1303-02xx (SFF 2x5 155M 1310nm 2km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	km	-	-	2	1
Center Wavelength Range	λc	nm	1260	1310	1360
Spectral Width(RMS)	Δλ	nm	-	-	4
Launch Optical Power	P₀	dBm	-15	-	-8	1
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-31	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-32
SD Hysteresis		dB	0.5	-	-	6

Table 5.3-GACF-1303-10xx (SFF 2x5 155M 1310nm 10Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	10	2
Center Wavelength Range	λc	nm	1260	1310	1360
Spectral Width(RMS)	Δλ	nm	-	-	4
Launch Optical Power	P₀	dBm	-15	-	-8	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-28	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-29
SD Hysteresis		dB	0.5	-	-	56

Table 5.4-GACF-1303-20xx (SFF 2x5 155M 1310nm 20Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	20	2
Center Wavelength Range	λc	nm	1260	1310	1360
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Side Mode Suppression Ratio	SMSR	dB	30	-	-
Launch Optical Power	P₀	dBm	-9	-	-3	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-28	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-29
SD Hysteresis		dB	0.5	-	-	6

Table 5.5-GACF-1303-40xx (SFF 2x5 155M 1310nm 40Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	40	2
Center Wavelength Range	λc	nm	1260	1310	1360
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	-6	-	0	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-30	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-31
SD Hysteresis		dB	0.5	-	-	6

Table 5.6-GACF-1303-60xx (SFF 2x5 155M 1310nm 60Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	60	2
Center Wavelength Range	λc	nm	1260	1310	1360
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	-3	-	+2	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-30	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-31
SD Hysteresis		dB	0.5	-	-	6

Table 5.7-GACF-1503-40xx (SFF 2x5 155M 1550nm 40Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	40	2
Center Wavelength Range	λc	nm	1500	1550	1600
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	-9	-	-3	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-30	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-31
SD Hysteresis		dB	0.5	-	-	6

Table 5.8-GACF-1503-80xx (SFF 2x5 155M 1550nm 80Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	80	2
Center Wavelength Range	λc	nm	1500	1550	1600
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	-6	-	0	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-32	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-33
SD Hysteresis		dB	0.5	-	-	6

Table 5.9-GACF-1503-K2xx (SFF 2x5 155M 1550nm 120Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	120	2
Center Wavelength Range	λc	nm	1500	1550	1600
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	0	-	+5	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-32	5
Saturated optical power	P_SAT	dBm	-3	-	-
SD De-Assert	SDD	dBm	-45	-	-
SD Assert	SDA	dBm	-	-	-33
SD Hysteresis		dB	0.5	-	-	6

Table 5.10-GACF-1503-K6xx (SFF 2x5 155M 1550nm 160Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	160	2
Center Wavelength Range	λc	nm	1500	1550	1600
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	+2	-	+7	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-35	5
Saturated optical power	P_SAT	dBm	-8	-	-

Table 5.11-GACF-1503-2Kxx (SFF 2x5 155M 1550nm 200Km)

Parameter	Symbol	Unit	Min.	Typ.	Max.	Notes
Optical transmitter Characteristics
Data Rate	BR	Mbps	-	155	-
Distance	L	Km	-	-	200	2
Center Wavelength Range	λc	nm	1500	1550	1600
Spectral Width(-20dBm)	Δλ	nm	-	-	1
Launch Optical Power	P₀	dBm	+2	-	+7	2
Extinction Ratio	ER	dB	8.2	-	-	3
Eye Diagram	Compliant with ITU-T G.957					4
Optical receive Characteristics
Data Rate	BR	Mbps	-	155	-
Operating Wavelength	λc	nm	1260	-	1610
Receiver Sensitivity	Sens	dBm	-	-	-41	5
Saturated optical power	P_SAT	dBm	-8	-	-

Note:

1. Coupled into 50/125 MMF

2. Coupled into 9/125 SMF

3. Filtered, measured with a PRBS 2^7-1 test pattern @155Mbps

4. Eye pattern mask, See Figure 1

5. Minimum average optical power at BER less than 1E-12, with a 2^7-1 NRZ PRBS and ER=9 dB

6. LOS Hysteresis, See Figure 2

Figure 1 Eye pattern mask

Figure 2 SD Hysteresis

SFF Transceiver Electrical Pad Layout

Figure 3 Case isolated from circuit ground

Pin Function Definitions

Table 6-Pin Function Definitions

Pin No.	Name	Function
1	Veer	Receiver Signal Ground
2	Vccr	3.3V DC power for receiver section
3	SD	Signal Detect Output (LVTTL) “1” -“Signal valid”, “0” – “Lose of signal”
4	RD-	Received Data Out Bar (CML)
5	RD+	Received Data Out (CML)
6	Vcct	3.3V DC power for transmitter section
7	Veet	Transmitter Signal Ground
8	TXDIS	Transmitter Disable (LVTTL), “1” – Disable, “0” – Enable
9	TD+	Transmitter Data In (CML)
10	TD-	Transmitter Data In Bar (CML)

Recommend Circuit Schematic

Figure 4 Recommended Interface Circuit

Mechanical Specifications

Figure 5 Mechanical Specifications

Regulatory Information

Table 7-List of Regulatory Compliance

Feature	Standard	Performance
Electrostatic Discharge (ESD) to the Electrical Pins	MIL-STD-883H Method 3015.8	Based on HBM
Electrostatic Discharge (ESD) to the Electrical Pins	IEC61000-4-2	8kV Contact Discharge 15kV Air Discharge
Electrostatic Discharge to the enclosure	EN 55024:1998+A1+A2 IEC-61000-4-2 GR-1089-CORE	Compatible with standards
Electromagnetic Interference (EMI)	FCC Part 15 Class B EN55022:2006 CISPR 22B :2006 VCCI Class B	Compatible with standards Noise frequency range: 30MHz to 6GHz. Good system EMI design practice required to achieve Class B margins. System margins are dependent on customer host board and chassis design.
Immunity	EN 55024:1998+A1+A2 IEC 61000-4-3	Compatible with standards. 1KHz sine-wave, 80% AM, from 80MHz to 1GHz. No effect on transmitter/receiver performance is detectable between these limits.
Laser Eye Safety	FDA 21CFR 1040.10 and 1040.11 EN (IEC) 60825-1:2007 EN (IEC) 60825-2:2004+A1	CDRH compliant and Class I laser product.
RoHS2.0	2011/65/EU	Compliant with standards

Notice

Gigac reserves the right to make changes to or discontinue any optical link product or service identified in this publication, without notice, in order to improve design and/or performance. Applications that are described herein for any of the optical link products are for illustrative purposes only. Gigac makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification.

Revision History

Version	Initiated	Reviewed	Revision History	Release Date
A0	Fei.Han	Sean.Lin	Initialization	2018-10-19
A1	Fei.Han	Sean.Lin	Amend parameter	2023-11-11

Contact

Add: Area 3-502, Haolang technology Park,

NO.2666, Konggang Four Road, Shuangliu district, 610207 Chengdu, China

Tel: (+86) 028-85124518

Fax: (+86) 028-85154518

Postal: 610207

E-mail: sales@gigac.com

Website: http://www.gigac.com

Our factory

Wavelength Divisio···

Detailed Explanati···

The Working Princi···

The Key Difference···

Hot Tags:

R&D laboratory

Gigac has introduced numerous precision testing equipment, such as Ixia XGS12, Ixia WaveTest 93, Anritsu, Fujikura, Fluke, JDSU, Agilent, EXFO, DATA-PIXEL, etc., for product development testing and validation.At present, there are over 100 professional engineers, of which 50% are senior engineers. Through standardized testing processes and in line with international professional testing standards, we provide testing in various aspects such as product appearance, performance, compatibility, and solution scenarios to meet the diverse testing needs of global customers.

Numerous research and development achievements

Gigac adopts a research and development model that combines independent research and joint development, and has achieved outstanding results in industrial design and product software and hardware research and development.As data centers continue to expand and grow, a well planned cabling infrastructure is crucial. Without flexible cabling plans that can easily adapt to common moves, additions, and changes, your network growth will be limited. The Gigac series high-density data center cabling solutions can simplify deployment, enabling up to 144 LC fibers in 1U, and enabling flexible expansion and rapid upgrades with increasing business traffic demands.

Gigac Test Center

Gain a comprehensive understanding of Gigac's optical modules, fiber optic jumpers, and enterprise network testing center. We have a comprehensive testing plan, professional testing equipment, and standard testing procedures. We regularly test optical modules, cables, switches, and other products to ensure that we provide high-quality products to our partners.

SFF Optical Transceiver

SFF 2x5 155M Duplex LC Series

Products Description

Our factory
