Products Description
The SFP+10G 100GHz DWDM optical module is a 100 GHz dense wavelength division multiplexing (DWDM) optical module packaged in SFP+format, supporting 10 Gigabit Ethernet transmission rates. 100GHz DWDM technology: This optical module adopts 100GHz DWDM technology, which can multiplex optical signals over a wide channel interval. This technology allows for the transmission of multiple signals of different wavelengths in optical fibers, achieving high-density and high bandwidth transmission. SFP+packaging: This optical module uses SFP+packaging, which has miniaturization and hot swappable functionality. It can be compatible with devices that support SFP+interfaces, making installation and replacement convenient. Fiber optic connection: SFP+10G 100GHz DWDM optical modules are connected to the fiber optic network infrastructure through fiber optics. Usually SC or LC type fiber optic connectors are used. 10 Gbps transmission rate: This optical module supports up to 10 Gbps transmission rate and is suitable for high-speed data transmission and broadband applications. SFP+10G 100GHz DWDM optical modules are typically deployed by telecommunications operators, data centers, or enterprise networks for long-distance fiber optic transmission and dense wavelength division multiplexing of optical networks. It provides high bandwidth, low latency data transmission capability, and supports simultaneous transmission of multiple wavelength signals.
Features
Available in all C‐Band Wavelengths on the 100GHz
Hot‐pluggable SFP+ package with Duplex LC receptacle connector
Operating Data Rate up to 10.3125Gbps
Link Distance up to 80km with 9/125μm SMF
Built‐in Digital Diagnostic Monitoring (DDM) function, Compliant with SFF‐8472
Single 3.3V Power Supply and CML Logic Interface
DWDM EML transmitter and high performance PIN‐TIA/APD receiver
Operating case temperature:
Standard(C):0°C~+70°C
Extended(E):‐20°C~+85°C
Industrial(I):‐40°C~+85°C
Ultra‐Industrial(UI):‐45°C~+95°C
Applications
10GBASE‐ER/ZR
DWDM Network
10Gbps Fiber Channel
Order Information：
Note1: Seetable6
Note2: Part Number "xxx" indicates that the wavelength form is determined, See Table-6, For example 1567.13nm wavelength product Number GDCP-C1396-40xx.
Note3: “x”=space,Standard:0°C~+70°C;“x”=E,Extended:-20°C~+85°C;“x”=I,Industrial:-40°C~+85°C,“x”=UI,Ultra-Industrial:-45°C~+95°C.
