Products Description

1.PRODUCT FEATURES

Support 2.5Gbase-T / 1000base-T/ 100base-T on line port

Support 2.5Gbase-X on host port

Hot-pluggable SFP footprint

Compact RJ-45 connector assembly

RoHS compliant and lead-free

Single +3.3V power supply

2.5 Gigabit Ethernet over Cat 5 cable

Ambient Operating temperature: 0°C to +70°C

Power dissipation <2W

2.PRODUCT DESCRIPTION

SFP-2.5GBASE-T-A Copper Small Form Pluggable (SFP) transceivers are based on the

SFP Multi Source Agreement (MSA) . They are compatible with the 2.5Gbase-T /

1000base-T/100base-T standards as specified in IEEE Std 802.3 . SFP-2.5GBASE-T-A

uses the SFP's RX_LOS(must be pulled up on host) pin for link indication. If pull up or

open SFP's TX_DISABLE pin, PHY IC be reset.

3. Cable Length

In the ingress direction, the entire packet is fully buffered prior to being transmitted out of Host port

at 2.5Gbps. In the egress direction, the 2.5Gbps packet is buffered since the line port at a slow

speed, the egress packet should be throttled to match the lower speed by extending the IPG

between packet. flow control can be enabled on the host side MAC to limit the flow of packets.
