Products Description

1.Features

Operating Data Rate up to 3Gbps

Up to 20km with 9/125 µm SMF

1310nm FP or 1550nm or 1490nm DFB Laser and PIN Receiver

Single 3.3V Power Supply and CML Logic

 Interface

Hot-Pluggable SFP Footprint BIDI LC Connector

Interface Class 1 FDA and IEC60825-1 Laser Safety Compliant

Operating Case Temperature

Standard:     0℃~+70℃

Compliant with SFP MSA Specification

Compliant with SFF-8472

RoHS6 compliance

2.Applications

Gigabit Ethernet

Supports video pathological patterns for SD-SDI, HD-SDI and 3G-SDI

Fiber Channel links

SONET/SDH Switch Infrastructure

3.General

The GIGAC's video series transceivers are high performance, cost effective modules for video transmission application over single mode fiber. The receiver is designed to receive data rates up to 2.97Gbps and is specifically designed for robust performance in the presence of SDI pathological patterns for SMPTE 259M, SMPTE 292M, DVB-ASI and SMPTE 424M serial rates.The receiver is consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA). All modules satisfy class I laser safety requirements.

4.Order Information

Table 1-Order Information

Part Number	Data Rate	Wavelength	Distance	Fiber	Interface	DDMI	Temp.
GABS-3524-10BT	3G	1310nm/1550nm	10km	SMF	LC	Y	C
GABS-5324-10BT	3G	1550nm/1310nm	10km	SMF	LC	Y	C
GABS-3524-20BT	3G	1310nm/1550nm	20km	SMF	LC	Y	C
GABS-5324-20BT	3G	1550nm/1310nm	20km	SMF	LC	Y	C
GABS-4524-20BT	3G	1490nm/1550nm	40km	SMF	LC	Y	C
GABS-5424-20BT	3G	1550nm/1490nm	40km	SMF	LC	Y	C
