Products Description
Features
Compliant with SFF-8431,SFF-8432 and IEE802.3ae
Supports rate up to 10.3 Gb/s bit rates
1G/2G/4G/ 8G/10G Fiber Channel applications.
Cooled EML transmitter and APD receiver
link length up to 80km
Low Power Dissipation 1.4W Typical (Maximum:2W)
Single 3.3V power supply
Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
For the OBSAI application, the rates are 6.144Gb/s, 3.072 Gb/s, 1.536 Gb/s and 0.768 Gb/s.
For the CPRI application, the rates are 6.144Gb/s, 3.072 Gb/s, 2.4576 Gb/s, 1.2288 Gb/s, 0.6144Gb/s.
RoHS6 compliant and lead free
Operating case temperature: Standard : 0 to +70°C Industrial : -40 to +85°C
Applications
10G Ethernet
10G Fiber Channel (with/without FEC)
For the OBSAI application, the rates are 6.144Gb/s, 3.072 Gb/s, 1.536 Gb/s and 0.768 Gb/s.
For the CPRI application, the rates are 6.144Gb/s, 3.072 Gb/s, 2.4576 Gb/s, 1.2288 Gb/s, 0.6144Gb/s.
Description
Gigac SFP+ 70km ~ 80km 1550nm Transceiver is a “Limiting module”, designed for 10GEthernet, and 2G/4G/ 8G/10G Fiber- Channel applications. The transceiver consists of two sections: The transmitter section incorporates a colded EMLlaser. Andthe receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy classI lasersafety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specifiedin SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
